32056L Rev. 2 12/4/01 105SL Maintenance Manual Page 6-23
OPTION KITS SECTION 6
10. Connect the coax cable from the host computer to the mating connector on the adapter
cable.
Figure 6-18. Coax Communications Interface Board Installation
(Printer Configurations 10500-0XXX-XXXX and 10500-1XXX-XXXX)
Figure 6-19. Coax Communications Interface Board Installation
(Printer Configurations 10500-2XXX-XXXX and 10500-3XXX-XXXX)
Interface
Board
Data
Cable
Connector
Interface
Data
Cable
