Zebra 105SL - Cutter Option

32056L Rev. 2 12/4/01 105SL Maintenance Manual Page 6-29
OPTION KITS SECTION 6
&877(5237,21
The cutter is a factory installed option.
Left Right Left Right 5 - Canada (French)
Left Right Right Left 6 - Denmark/Norway
Left Right Right Right 7 - Finland/Sweden
Right Left Left Left 8 - France
Right Left Left Right 9 - Italy
Right Left Right Left A - Japan
Right Left Right Right B -Japan (English)
Right Right Left Left C - Portugal
Right Right Left Right D - Spain
Right Right Right Left E - Spanish Speaking
Right Right Right Right F - United Kingdom
NOTE: The language character sets 1 - US/Canada and B - Japan (English) are the same. The character
sets for D - Spain and E - Spanish Speaking are the same.
Cable Address Switch Settings
Switch #9 Switch 10 Switch 11 Address Selected
Left Left Left 0 – (Factory Setting)
Left Left Right 1
Left Right Left 2
Left Right Right 3
Right Left Left 4
Right Left Right 5
Right Right Left 6
Right Right Right 7 – (Use in Diagnostic Mode Only)
Star Panel Overdrive
Switch 12 Description
Left Normal Operation
Table 6-6. Setting Printer Configuration for Twinax
Parameter Setting
Table 6-5. Twinax Dip Switch Setting (Continued)
