SECTION 3 TROUBLESHOOTING
&RPPXQLFDWLRQV'LDJQRVWLFV7HVW
This test is controlled by configuring the “Setting Communications Mode” parameter found in
the configuration section of the printer’s User’s Guide. Refer to Figure 3-4 for a sample label
resulting from this test.
NOTE: This label is inverted when printed.
Figure 3-3. FEED Key Self Test Sample Label
Figure 3-4. Communications Diagnostics Self Test
