RW Series Quick Start Guide
Using the Accessories
Belt Clip (standard on all printers)
Adjustable Shoulder Strap (optional)
To use: hook the clip over your belt and ensure that the clip is
securely attached to the belt. The belt clip will pivot to allow you
to move freely while wearing the printer.
Refer to figure below. Snap each end of the shoulder strap into the
“D” rings in the top of the printer. Hold the buckle and slide the strap
as shown below until you achieve the desired length.
Section Continues
Printer can pivot freely
Hold
Buckle
Pull Strap here to
lengthen
Pull Strap here
to shorten
Snap in to “D”
rings on Printer
Clip Printer to belt
