RW Series User Guide
Figure 29: RW 420 Overall Dimensions
1.8” [46 mm]
.25” [6 mm]
6.9” [175 mm]
7.4” [188 mm]
3.7”
[94 mm]
max.
1
3.2”
[81 mm]
max.
1
6.3”
[160 mm]
NOTE:
1. Dimensions shown are for units
with the MSR/Smart Card option
installed. Subtract .08” [2 mm]
from these dimensions for units
without this option.
