Zebra RW SERIES User Manual

9
RW Series User Guide
Figure 2: RW 220 Overview
1
1. Platen Roller
2. Bar Sensor
3. Media Support Disks
4. Printhead
5. Latch Release Button
6. Magnetic Stripe Reader
(MSR) Slot
7. “D” Rings
8. Control Panel
9. Smart Card Slot
10. Gap Sensor
11. Media Cover
12. Communications
Port Door
13. Communications Port
14. Belt Clip
15. Battery
16. Battery Charging Receptacle
2
3
4
5
6
7
8
10
11
9
15
12
14
16
7
13
