TC72/TC77 Quick Start Guide
20
3. Insert the battery, bottom first, into the battery compartment in the back of the device.
Figure 20 Insert Bottom of Battery into Battery Compartment
4. Press the battery down into the battery compartment until the battery release latches snap into place.
Figure 21 Press Down on Battery
5. Place hand strap clip into hand strap mounting slot and pull down until it snaps into place.
Figure 22 Secure Hand Strap Clip
