Zebra TC72 Quick Start Guide

TC72/TC77 Quick Start Guide
22
Charging the Device
Use one of the following accessories to charge the device and/or spare battery.
Charging the TC72/TC77
NOTE: Ensure that you follow the guidelines for battery safety described in the device User Guide.
1. Insert the device into the charging slot or connect the USB Charge cable to the device.
2. Ensure the device is seated properly.
The Notification/Charge LED lights amber while charging, then turns solid green when fully charged. See
Table 2 for charging indicators.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Table 1 Charging and Communication
Description Part Number
Charging Communication
Battery
(In Device)
Spare Battery USB Ethernet
2-Slot Charge
Only Cradle
CRD-TC7X-SE
2CPP-01
Yes Yes Yes No
2-Slot
USB/Ethernet
Cradle
CRD-TC7X-SE
2EPP-01
Yes Yes Yes Yes
5-Slot Charge
Only Cradle
CRD-TC7X-SE
5C1-01
YesNoNoNo
4-Slot Charge
Only Cradle
with Battery
Charger
CRD-TC7X-SE
5KPP-01
Yes Yes No No
5-Slot Ethernet
Cradle
CRD-TC7X-SE
5EU1–01
Yes No No Yes
4-Slot Spare
Battery Charger
SAC-TC7X-4B
TYPP-01
No Yes No No
Snap-On USB
Cable
CBL-TC7X-CB
L1-01
Yes No Yes No
Charging Cable
Cup
CHG-TC7X-CL
A1-01
YesNoNoNo

Zebra TC72 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Internal memory	4 GB
Internal memory type	-
Total storage capacity	32 GB
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Rear camera aperture number	2.4
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Scanner type	1D/2D
Product color	Black, Silver
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
