Zebra TC72 Quick Start Guide

TC72/TC77 Quick Start Guide
23
Charging the Spare Battery
1. Insert a spare battery into the spare battery slot.
2. Ensure the battery is seated properly.
The Spare Battery Charging LED blinks indicating charging. See Table 3 for charging indicators.
The 4,620 mAh battery fully charges in less than five hours at room temperature.
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37°C (+98°F))
the device or cradle may for small periods of time alternately enable and disable battery charging to keep the
Table 2 Charging/Notification LED Charging Indicators
State Indication
Off The device is not charging. The device is not inserted correctly in
the cradle or connected to a power source. Charger/cradle is not
powered.
Slow Blinking Amber (1 blink every 4
seconds)
The device is charging.
Solid Green Charging complete.
Fast Blinking Amber (2 blinks/second) Charging error, e.g.:
Temperature is too low or too high.
Charging has gone on too long without completion (typically eight
hours).
Slow Blinking Red (1 blink every 4
seconds)
The device is charging but the battery is at end of useful life.
Solid Red Charging complete but the battery is at end of useful life.
Fast Blinking Red (2 blinks/second) Charging error but the battery is at end of useful life., e.g.:
Temperature is too low or too high.
Charging has gone on too long without completion (typically eight
hours).
Table 3 Spare Battery Charging LED Indicators
State Indication
Off The battery is not charging. The battery is not
inserted correctly in the cradle or connected to a
power source. Cradle is not powered.
Solid Amber Battery is charging.
Solid Green Battery charging is complete.
Fast Blinking Red
(2 blinks/second)
Charging error, e.g.:
- Temperature is too low or too high.
- Charging has gone on too long without completion
(typically eight hours).
Solid Red Unhealthy battery is charging or fully charged.

Zebra TC72 Specifications

General

Display diagonal	4.7 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Internal memory	4 GB
Internal memory type	-
Total storage capacity	32 GB
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Rear camera aperture number	2.4
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Scanner type	1D/2D
Product color	Black, Silver
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
