Preparing the Printer for Use
4/8/14 ZT400™ Series Quick Reference Guide P1060608-003
Preparing the Printer for Use
After you have familiarized yourself with the printer components, prepare the printer for use.
To set up the printer, complete these steps:
1. Select a location for the printer that meets these conditions:
•must be a solid, level surface of sufficient size and strength to hold the printer
•must include enough space for ventilation and for accessing the printer components
and connectors
•should be within a short distance of an appropriate power outlet that is easily
accessible
2. Unpack and inspect the printer. If necessary, report any shipping damage. For more
information, refer to the User Guide.
3. Place the printer in the preselected location.
4. Plug the female end of the A/C power cord into the A/C power connector on the back of
the printer.
Caution • When you are loading media or ribbon, remove all jewelry that could come into
contact with the printhead or other printer parts.
Caution • Before touching the printhead assembly, discharge any built-up static electricity
by touching the metal printer frame or by using an anti-static wriststrap and mat.

Zebra ZT400 Specifications

General

Print Method	Thermal Transfer and Direct Thermal
Supported Media Types	Continuous, Die-cut, Notch, Black-mark
Print Width	104 mm (4.09 in)
Print Resolution	203 dpi/8 dots per mm, 300 dpi/12 dots per mm optional
Max Print Speed	356 mm per second (14 ips)
Memory	512 MB Flash
Connectivity	USB 2.0, RS-232 Serial, 10/100 Ethernet, Bluetooth
Media Sensors	Reflective, Transmissive
Operating Temperature	0° to 40° C (32° to 104° F)
Media Width	19.4 mm to 114 mm (0.75 in to 4.5 in)
Media Length	991 mm (39 in)
Ribbon Length	450 m
Storage Temperature	-40º F to 140º F/-40º C to 60º C
Weight	16.33 kg (36 lbs)
Power Requirements	100-240 VAC, 50/60 Hz
Ribbon Width	51 mm to 110 mm (2.00 in to 4.33 in)
