Preparing the Printer for Use
4
P1060608-003 ZT400™ Series Quick Reference Guide 4/8/14
5. Plug the male end of the A/C power cord into an appropriate power outlet.
6. Connect the printer to a computer using one or more of the available connections. The
standard connections are shown here. A parallel connection or a wireless connection may
also be available on your printer.
Internal wired Ethernet print server
Serial port
USB port
115 V AC
230 V AC

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZT400 and is the answer not in the manual?

Zebra ZT400 Specifications

General IconGeneral
Print MethodThermal Transfer and Direct Thermal
Supported Media TypesContinuous, Die-cut, Notch, Black-mark
Print Width104 mm (4.09 in)
Print Resolution203 dpi/8 dots per mm, 300 dpi/12 dots per mm optional
Max Print Speed356 mm per second (14 ips)
Memory512 MB Flash
ConnectivityUSB 2.0, RS-232 Serial, 10/100 Ethernet, Bluetooth
Media SensorsReflective, Transmissive
Operating Temperature0° to 40° C (32° to 104° F)
Media Width19.4 mm to 114 mm (0.75 in to 4.5 in)
Media Length991 mm (39 in)
Ribbon Length450 m
Storage Temperature-40º F to 140º F/-40º C to 60º C
Weight16.33 kg (36 lbs)
Power Requirements100-240 VAC, 50/60 Hz
Ribbon Width51 mm to 110 mm (2.00 in to 4.33 in)
