2: Installation and Setup

Loading the Laminate

P1036101-001 Zebra ZXP Series 7 Card Printer User’s Manual 27

Step 3. Ensure the cassette is fully seated on the spindle. Gently press the cassette until it is

flush against the laminator frame.

Step 4. Rotate each cassette (in the direction indicated in the figure below) until it stops.

Other manuals for Zebra ZXP 7 series

Questions and Answers:

Need help?

Do you have a question about the Zebra ZXP 7 series and is the answer not in the manual?

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
