2: Installation and Setup
Installing the Manual Feed Cleaning Cassette
P1036101-002 Zebra ZXP Series 7 Card Printer User’s Manual 13
Installing the Manual Feed Cleaning Cassette
The Manual Feed Cleaning Cassette cleans the cards entering the Printer from the Manual
Feed Slot. The cassette consists of a frame and an adhesive roller.
Step 1. Locate the cassette frame and adhesive roller.
Step 2. Insert the adhesive roller into the cassette frame.
Step 3. Peel the protective wrapper from the adhesive roller to expose the sticky surface.
Do not touch the sticky surface.
Step 4. The Manual Feed Cleaning Cassette is ready to use.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
