Zebra ZXP Series 7 User Manual

16 Zebra ZXP Series 7 Card Printer User’s Manual P1036101-002
2: Installation and Setup
Loading a Print Ribbon
Step 5. Take the print ribbon out of the box.
Step 6. Carefully unroll the print ribbon. Note that there is a clear leader with a sticky
surface holding the print ribbon in place. This leader needs to be pulled free and
rolled onto the take-up spool.
Step 7. Make sure the print ribbon comes off the bottom of the supply spool and feeds to the
bottom of the take-up spool.
Step 8. Set the print ribbon supply spool (PURPLE) into the supply carrier (PURPLE).
Step 9. Set the empty take-up spool (BLUE) into the take-up carrier (BLUE).
Step 10. Rotate the spools as required to take up excess slack in the ribbon.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
