Zebra ZXP Series 7 User Manual

P1036101-002 Zebra ZXP Series 7 Card Printer User’s Manual 1
1
Introduction
Description
This Manual provides detailed information on the installation and operation of Zebra
ZXP Series 7 Card Printers manufactured by Zebra Technologies Corporation.
The ZXP Series 7 offers the choice of single- or dual-sided direct to card printers with a range
of options that can be installed in the factory or added later so the printer can be scaled as
business needs grow or demands change.
The single-sided Laminator lays down and seals a laminating film on the top surface of the
printed card for added security; the dual-sided Laminator lays down and seals laminating
film on both the top and bottom surfaces of the printed card. A variety of Laminating Films
are available for specific uses; for details, go to
http://www.zebra.com/supplies.
References to “the printer” in this document apply to either the single-sided or the dual-
sided Printer.; similarly, references to “the laminator” apply to either the single-sided or the
dual- sided Laminator.

Zebra ZXP Series 7 Specifications

General

Display	LCD
Lamination	Yes
Certification	FCC A, ENERGY STAR
Product color	Black
Total input capacity	200 sheets
Display number of characters	21
Card types	PVC, PVC Composite
Print technology	Dye-sublimation/Thermal transfer
Maximum resolution	300 DPI
Print speed (color)	300 card/h
Print speed (monochrome)	1375 card/h
Printing media thickness	250 - 1270 µm
Duplex print speed (color)	225 card/h
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	964 x 277 x 306 mm
