ZEKS Eclipse ZPA 90-5000 Desiccant Dryers
www.zeks.com
3
Nominal Flow Type/Design Voltage Electrical
SCFM* Series (Dew Point) NEMA Option
90 ZPA = Pressure Swing 1 = 115-1-60 (-40°F) 0 = NEMA 1 0 = Standard
120 G = 115-1-60 (-80°F) H = NEMA 4 A = Failure-To-Shift (FTS)
160 B = 115-1-60 (-100°F) S = NEMA 4X B = High Humidity (HH)
200 2 = 230-1-60 (-40°F) Stainless Steel C = FTS + HH
250 C = 230-1-60 (-100°F) E = Dew Point Display
300 3 = 220-1-50 (-40°F) + MLC (NEMA 4/4X)
400 E = 220-1-50 (-100°F) G = Dew Point Display + MLC
500 + FTS (NEMA 4/4X)
600 M = Moisture Load Control (MLC)
800 + FTS (NEMA 1 only)
1000 N = MLC + HH (NEMA 1 only)
1200
1500
1800
2100
2700
3300
4000
5000
* Nominal Flows indicated are
for 100F inlet temperature,
100
°F ambient temperature and
100 psig compressed air pressure.
3.0 NOMENCLATURE
4.1 INSPECTION
Upon receiving your ZEKS air dryer, please inspect the unit
closely. If evidence of rough handling is detected, please
note it on your delivery receipt, especially if the dryer will
not be uncrated immediately. Obtaining the delivery per-
son’s signed agreement to noted damages will facilitate
submission of insurance claims.
4.2 UNPACKING AND HANDLING
Refer to labels on the dryer for the appropriate means for
lifting or moving the dryer. For those dryers that indicate
lifting via the structural skid, forks should extend all the
way through the skid to reduce unnecessary forces to the
dryer when moving. When lifting the dryer, ensure that
no stress is applied to the piping or the valves. Refer to
Section 8.2 for locating and mounting of dryer.
4.0 RECEIVING AND INSPECTION
!
NOTICE
Nomenclature shown above represents standard
price sheet options. Other options are available -
refer to nomenclature insert specifi c to your dryer
for details.
!
NOTICE
Under no circumstances should any person attempt
to lift heavy objects without proper lifting equipment
(i.e.: crane, hoist, slings or fork truck). Lifting any unit
without proper lifting equipment can cause serious
injury.
