ZEKS Eclipse
TM
90-5,000ZPB Desiccant Dryers
www.zeks.com
12.0 GENERAL ARRANGEMENT
*3(148:7*)447
DRYER MAIN PANEL
ITEM NO. PART NO. DESCRIPTION
1 47606394001 Dryer Controller with Program (Dryer Model and Serial Number must be provided when ordering)
2 23702244 Display Board, Panel
3 634083 Overlay, Controller
4 47587161001 Power Supply, 5VDC/24VDC
5 38052411 Transducer Cable, 5 Ft. Lead (Fail-To-Shift Optioned Units Only)
6 38052395 Transducer, 0-300 PSIA (Fail-To-Shift Optioned Units Only)
7 23174022 Repeater, Current Loop 4-20mA (4-20mA PDP Output Optioned Units Only)
52
