ZEKS Eclipse 90ZPB - 16.0 ENGINEERING SPECIFICATIONS

16.0 ENGINEERING SPECIFICATIONS
Inlet Flow Desiccant
-40°F -100°F Air Dimensions Shipping Weight
Dew Point Dew Point Purge Flow Connection Width Depth Height Weight (per Dryer)
MODEL SCFM SCFM (m3/h) In/Out Inches Inches Inches Lbs. Lbs.
90ZPB 90 72 14 1” NPT 40.50 30.00 63.12 475 100
120ZPB 120 96 19 1” NPT 40.50 30.00 63.12 563 134
160ZPB 160 128 26 1.5” NPT 44.50 32.00 66.12 707 192
200ZPB 200 160 30 1.5” NPT 44.50 32.00 66.12 731 236
250ZPB 250 200 40 1.5” NPT 48.50 32.00 66.81 869 290
300ZPB 300 240 48 2” NPT 48.50 32.00 66.81 924 344
400ZPB 400 320 65 2” NPT 52.50 36.19 67.81 1,115 470
500ZPB 500 400 81 2” NPT 56.50 39.69 82.50 1,564 638
600ZPB 600 480 93 2” NPT 56.50 42.40 82.50 1,664 748
800ZPB 800 640 130 3” NPT 64.00 51.25 87.62 2,017 900
1000ZPB 1,000 800 162 3” NPT 64.00 51.25 87.62 2,237 1,100
1200ZPB 1,200 960 195 3” NPT 64.00 51.25 87.62 2,424 1,270
1500ZPB 1,500 1,200 243 4” NPT 78.00 54.76 80.00 2,974 1,600
1800ZPB 1,800 1,440 292 4” NPT 84.00 60.62 91.88 3,905 2,000
2100ZPB 2,100 1,680 340 4” NPT 84.00 60.62 91.88 4,279 2,340
2700ZPB 2,700 2,160 438 4” NPT 84.00 60.76 91.88 4,926 2,928
3300ZPB 3,300 2,640 535 6” NPT 96.00 66.00 100.00 2,950
*
4,000
4000ZPB 4,000 3,200 649 6” NPT 96.00 66.00 100.00 3,000
*
4,400
5000ZPB 5,000 4,000 811 6” NPT 102.00 72.00 92.00 3,950
*
5,600
!
NOTICE
Specifi cation information shown above was accuate at time
this Technical Manual was published. Refer to the Serial Label
on the equipment for actual unit specifi cations.
* Dryer weight shown does not include desiccant. Desiccant is shipped separately with these models.
NOTE: All dryers in the table above rated at 150 psig, 120°F maximum inlet temperature.
Capacity and purge fl ow are based on standard inlet conditions of 100°F ambient air
temperature @ 100 psig pressure and will vary at different inlet conditions.
