ZEKS Eclipse
TM
90-5,000ZPB Desiccant Dryers
www.zeks.com
69
15.0 SPARE PARTS
ITEM NO. PART NO. DESCRIPTION
1 47606405001 Solenoid Valve with Gasket and Mounting Hardware (Individual valve)
2 104422 Filter Regulator Element
3 81322547 DIN Connector, Solenoid Valve, right angle, with Gasket and Cord
4 705001-SP Blue Moisture Indicator
CONTROL AIR SOLENOID and FILTER/REGULATOR ASSEMBLY
(Optional Dew Point Transmitter not shown.)
PART NO. DESCRIPTION
633671 Cable, Transmitter
633691 Resistor, 250 OHM (R3 on wiring diagram)
633856 Transmitter, Dewpoint (MIC-1 on fl ow diagram)
MOISTURE LOAD CONTROL (MLC) REPLACEMENT PARTS
Mounting location for optional
Moisture Load Control (MLC)
Transmitter and Sample Block.
(!) WARNING: Valves equipped with
manual override. Do not operate unless
you are a trained technician.
