COMPONENT PARTS LIST
RC REF PART# DESCRIPTION
CM151 4-17 CA - COMPONENTS
RC REF PART# DESCRIPTION
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
SEE REFERENCE CHART ON PAGE 4-128
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3208 022-08317-08 CAP, 10 MFD 20% 250V,
ELECTRO
MOQSUWa CX3210 022-08386-01 CAP, 270 PFD 10% 2000V,
CERAMIC DISC
XY CX3211 022-08386-08 CAP, 1000 PFD 10% 2000V,
CERAMIC DISC
JKLMNOPQRSTUVWZa CX3212 022-08386-05 CAP, 560 PFD 10% 2000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3215 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3216 022-08229-27 CAP, 0.013 MFD 3% 1600VDC,
POLYPROPYLENE
XY CX3217 022-08231-11 CAP, 0.39 MFD 5% 200V,
POLYPROPYLENE
JKLNPRTVZ CX3217 022-08231-12 CAP, 0.47 MFD 5% 200V,
POLYPROPYLENE
ABCDEFGHI CX3217 022-08231-13 CAP, 0.56 MFD 5% 200V,
POLYPROPYLENE
MOQSUWa CX3217 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3218 022-08315-05A CAP, 2.2 MFD 20% 160V,
ELECTRO
JKLMNOPQRSTUVWZa CX3219 022-08227-04A CAP, 0.022 MFD 5% 50V,
POLYESTER
MOQSUWa CX3251 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3253 022-08312-11A CAP, 47 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3254 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3400 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC
DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3401 022-07867-10 CAP, 0.1 MFD 20% 250VAC,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3402 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC
DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3403 022-07811A CAP, 1000 PFD 10% 1000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3404 022-07811A CAP, 1000 PFD 10% 1000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3405 022-07811A CAP, 1000 PFD 10% 1000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3406 022-07811A CAP, 1000 PFD 10% 1000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3407 022-08444-09 CAP, 330 MFD 20% 200V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3408 022-07786-10C CAP, 470 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3409 022-08386-08 CAP, 1000 PFD 10% 2000V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3410 022-07786C CAP, 1000 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3411 022-08049-18A CAP, 0.033 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3412 022-07786C CAP, 1000 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3413 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3415 022-08008-12 CAP, .01 MFD 5% 1250V,
POLYPROPYLENE
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3416 022-08310-12A CAP, 100 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3418 022-07786-01C CAP, 220 PFD 10% 500V,
CERAMIC DISC
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3420 022-08444-07 CAP, 220 MFD 20% 200V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3424 022-08310-16 CAP, 1000 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3430 022-08310-15 CAP, 470 MFD 20% 25V,
ELECTRO
CEGKNORSVWY CX6027 022-08309-15A CAP, 470 MFD 20% 16V,
ELECTRO
BCDEHJKLMNOTUVWa D1401 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D2201 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D2202 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D2203 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D2204 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D2205 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
XY D2207 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
XY D2208 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
XY D2209 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
HTUVWXY D2210 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
HTUVWXY D2211 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
HTUVWXY D2212 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
HTUVWXY D2501 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
HTUVWXY D2502 103-00347-03A DIODE, LOW VOLTAGE
GENERAL, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa D3410 103-00589 DIODE, FAST RECOVERY
RECTIFIER, 400 PIV
ABCDEFGHIJKLMNOPQRSTUVWXYZa D3411 103-00589 DIODE, FAST RECOVERY
RECTIFIER, 400 PIV
ABCDEFGHIJKLMNOPQRSTUVWXYZa D5101 103-00279-04A DIODE, ZENER, 3V 0.5W
ABCDEFGHIJKLMNOPQRSTUVWXYZa D5102 103-00344-06A DIODE, LOW VOLTAGE
GENERAL
ABCDEFGHIJKLMNOPQRSTUVWXYZa D6001 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa D6002 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa DAG0000 A-19197 GROUNDING ASSY , WIRE AND
TERMINAL, WHITE, DAG
ABCDEFGHIJKLMNOPQRSTUVWXYZa DAG0001 A-19197 GROUNDING ASSY , WIRE AND
TERMINAL, WHITE, DAG
FGIPQRSXYV DL2200 223-00045 INTD CKT PKG, NTSC COMB
FILTER, HYBRID
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2101 103-00347-03A DIODE, LOW VOLTAGE
GENERAL, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2102 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2103 103-00461A DIODE, ULTRA FAST
SWITCHING, HIGH
CONDUCTANCE
ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2104 103-00339-04A DIODE, LOW VOLTAGE
GENERAL, SILICON
