COMPONENT PARTS LIST
RC REF PART# DESCRIPTION
CM151 4-19 CA - COMPONENTS
RC REF PART# DESCRIPTION
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
SEE REFERENCE CHART ON PAGE 4-128
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1206 020-04506A COIL, RCF, FIXED, SHIELDED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L1207 020-04277-23A COIL, 12 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L2201 020-04129-22 COIL, 15 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L2202 020-04129-16 COIL, 4.7 MICROHENRY, RCF,
FIXED
HTUVWXY L2501 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
HTUVWXY L2502 020-03907-12A COIL, 10 MICROHENRY, RCF,
FIXED
HTUVWXY L2503 020-03907-12A COIL, 10 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L3405 020-04462-18A COIL, 33 MICROHENRY, RCF,
FIXED
HTUVWXY L3407 020-03907-21A COIL, 56 MICROHENRY, RCF,
FIXED
ABCDEFGIJKLMNOPQRSZa L3407 020-03907-24A COIL, 100 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L5101 020-03907-28A COIL, 220 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L5102 063-10246-46 RESISTOR, FILM, 1.2M OHM
10% 1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa L5103 149-00583-01 CORE, FERRITE BEAD
CEGKNORSVWY L6000 020-03907-24A COIL, 100 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L6001 020-04129-16 COIL, 4.7 MICROHENRY, RCF,
FIXED
FGHIPQRSTUVWXYZ L6002 020-04277-10A COIL, 1.0 MICROHENRY, RCF,
FIXED
ABCDEJKLMNOa L6002 020-04277-20A COIL, 6.8 MICROHENRY, RCF,
FIXED
ABCDEFGHIJKLMNOPQRSTUVWXYZa L6003 020-04129-08 COIL, 1 MICROHENRY, RCF,
FIXED
FGHILMNOPQRSTUVWXYZ L6004 020-04129-08 COIL, 1 MICROHENRY, RCF,
FIXED
FGHILMNOPQRSTUVWXYZ L6005 020-04129-08 COIL, 1 MICROHENRY, RCF,
FIXED
ABCDEJK L6005 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
ABCDEFGHIJKLMNOPQRSTUVWXYZa L6007 020-04129-16 COIL, 4.7 MICROHENRY, RCF,
FIXED
MOQSUWa LX3201 022-08231-10 CAP, 0.33 MFD 5% 200V,
POLYPROPYLENE
ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3202 149-00540-01 CORE, FERRITE
ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3262 020-04073-03 COIL, RCF
ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3401 095-04593 TRANSFORMER, LINE CHOKE
ABCDEFGHIJKLMNOPQRSTUVWXYZaLX3403 149-00540-01 CORE, FERRITE
ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3404 149-00540-01 CORE, FERRITE
ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3410 149-00549 CORE, FERRITE, WITH
CAPTIVATED THRU-LEAD
HTUVWXY PIP 009-02107 MODULE, SINGLE PIP, CA
CHASSIS
HTUVWXY PIPA 058-00605-10 PLUG, MULTIPRONG, 10
POSITION
HTUVWXY PIPB 058-00605-10 PLUG, MULTIPRONG, 10
POSITION
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q0800 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1200 121-01261A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1201 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1202 121-01310A TRANSISTOR, NPN, SILICON
FGIPQRSXYZ Q1401 121-01310A TRANSISTOR, NPN, SILICON
FGIPQRSXYZ Q1402 121-01310A TRANSISTOR, NPN, SILICON
FGIPQRSXYZ Q1403 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2201 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2202 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2203 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2204 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2205 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2206 121-01311A TRANSISTOR, PNP, SILICON
XY Q2207 121-01390 TRANSISTOR, NPN, SILICON
ABCDEHJKLMNOTUVWa Q2208 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2209 121-01311A TRANSISTOR, PNP, SILICON
HTUVWXY Q2210 121-01391A TRANSISTOR, PNP, SILICON
HTUVWXY Q2501 121-01310A TRANSISTOR, NPN, SILICON
HTUVWXY Q2502 121-01310A TRANSISTOR, NPN, SILICON
HTUVWXY Q2503 121-01310A TRANSISTOR, NPN, SILICON
HTUVWXY Q2504 121-01310A TRANSISTOR, NPN, SILICON
HTUVWXY Q2505 121-01311A TRANSISTOR, PNP, SILICON
XY Q2902 121-01311A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3201 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3202 121-01264-01A TRANSISTOR, NPN SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3402 121-01340A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3403 121-01340A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3404 121-01102A TRANSISTOR, PNP, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5101 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5102 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5103 121-01291-01 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5104 121-01140A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q6001 121-01310A TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa Q6002 121-01310A TRANSISTOR, NPN, SILICON
XY Q6003 121-01390 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3203 121-01383 TRANSISTOR, NPN, SILICON
ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3203 126-03626-01 HEAT SINK, TRANSISTOR,
HORIZONTAL OUTPUT
ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3401 121-01348 TRANSISTOR, NPN, SILICON,
80V/1A
ABCDEFGHIJKLMNOPQRSTUVWXYZa R0843 063-10235-60 RESISTOR, FILM, 330 OHM 5%
1/4W
FGIPQRSXYZ R0851M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
BCDEHJKLMNOTUVWa R0851M 063-11059-89A RESISTOR, THICK FILM CHIP,
47K OHM 5% 1/10W
BCDEFGHIJKLMNOPQRSTUVWXYZa R0852M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R0853 063-10235-12 RESISTOR, FILM, 3.3 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R0854M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
FGIPQRSXYZ R0861M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
A R0861M 063-11059-76A RESISTOR, THICK FILM CHIP,
13K OHM 5% 1/10W
BCDEHJKLMNOTUVWa R0861M 063-11059-89A RESISTOR, THICK FILM CHIP,
47K OHM 5% 1/10W
BCDEFGHIJKLMNOPQRSTUVWXYZa R0862M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
A R0862M 063-11059-59A RESISTOR, THICK FILM CHIP,
2.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R0863 063-10235-12 RESISTOR, FILM, 3.3 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R0864M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
CEGKNORSVWY R1200M 063-11059-97A RESISTOR, THICK FILM CHIP,
100K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R1201M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R1202M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R1203M 063-11059-39A RESISTOR, THICK FILM CHIP,
390 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R1204M 063-11059-53A RESISTOR, THICK FILM CHIP,
1.5K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R1205M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
