BC3500DLM / BC3500DWM
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a
symbol concern critical points which must be taken into
consideration to prevent possible serious bodily injury, and for
this reason you are requested to read all such instructions care-
fully and follow them without fail.
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in order
to prevent accidents, which could lead to serious bodily injury
or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
Contents
1. Parts location ...................................................4
2. Specifications ...................................................5
3. Warning labels on the machine .......................5
4. Symbols on the machine ..................................5
5. For safe operation ............................................6
6. Set up ...............................................................9
7. Fuel ................................................................11
8. Operation .......................................................12
9. Maintenance ..................................................16
10. Storage ...........................................................17
11. Troubleshooting guide ...................................17
12. Disposal .........................................................18
1. Parts location
BC3500DLM
16
11
15
12
13
14
1
2
3
4
5
BC3500DWM
1
2
3
5
6
7
8
9
10
11
12
13
14
4
6
7
8
10
(1) Primer
(2) Air cleaner cover
(3) Choke lever
(4) Fuel tank
(5) Starter knob
(6) Trimmer head
(7) Angle transmission
(8) Cutting Attachment guard
(9) Loop handle
(10) Shaft tube
(11) Suspention point
(12) Throttle trigger
(13) Stop switch
(14) Throttle cable
(15) Hip pad
(16) Handle
