Zenoah BC3500DLM - Setup and Assembly Procedures

GB-9
BC3500DLM / BC3500DWM
G
B
6. Set up
A Package contains the items as illustrated.
(1) Unit (BC3500DLM)
(2) Unit (BC3500DWM)
(3) Hip pad (BC3500DWM)
(4) Band
(5) Harness (BC3500DLM)
(6) Harness (BC3500DWM)
(7) Handle (BC3500DWM)
(8) Handle (BC3500DWM)
(9) Bolt (BC3500DLM)
(10) Handle (BC3500DLM)
(11) Cutting attachment guard
(12) Guard skirt
(13) Output shaft
(14) Trimmer head
(15) Cover
(16) Blade cover
(17) Hexagon socket (S17/S19)
(18) Bar (Φ4.5)
(19) Wrench
(20) Wrench
(21) Screw driver
(22) Owner’s manual
4
9
5
1
15
14
11
12
10
BC3500DLM
BC3500DWM
3
17
18
19
16
7
8
20
22
21
13
6
BC3500DWM
BC3500DWM
BC3500DLM
2
BC3500DWM
BC3500DLM
