8
• Mix gasoline (octane over 95) and high grade 2 cycle engine oil (mixing use
type; JASO FC grade or ISO-L-EGC grade) at mixing ratio 25:1.
• The mixing ratio is according to the oil recommendation.
[ NOTE ]
1) Gasoline may contain maximum of 10% Ethanol (grain alcohol) or up to 15%
MTBE (Methyl tertiary-butyl ether).
Gasoline containing Methanol (Wood Alcohol) is NOT approved.
2) Gasoline is very flammable. Avoid smoking and any fires near fuel.
3) To prevent all possible problems on fueling system, make sure to use the fuel
filter which has more than 300 mesh or equivalent and gasoline proof rubber
pipe or equivalent.
Incorrect fuel filter may cause engine trouble like fuel passage stuffing in
carburetor, or piston surface scratching etc.
4) When fueling, make sure that no fuel touches the hot parts.
5) Assemble the fuel line so that it does not touch the hot parts. Also, check that
there is no fuel leakage due to cracks, or hardening.
Fueling System
