Zephyr Essentials ZAN-E30CS User Manual

1
SAFETY NOTICE ................................................................. 2-3
LIST OF MATERIALS ....................................................... 4
INSTALLATION
Ducting Calculation Sheet ....................................... 5
Mounting Height & Clearance ................................ 6
Ducting Options ........................................................... 7
Hood Specications ................................................... 8 - 11
Mounting the Hood ..................................................... 12
Ductless Recirculating .............................................. 13
FEATURES & CONTROLS
ICON Touch Controls ................................................ 14 - 15
MAINTENANCE
Hood and Filter Cleaning ......................................... 16
ACT CONVERSION ..................................................................... 17
WIRING DIAGRAMS ................................................................... 18
FAN CURVE DIAGRAMS ......................................................... 19 - 20
TROUBLESHOOTING................................................................ 21
LIST OF PARTS AND ACCESSORIES .............................. 22
WARRANTY .................................................................................... 23
PRODUCT REGISTRATION .................................................... 24
Table of Contents

Zephyr Essentials ZAN-E30CS Specifications

General

Color	stainless steel
Hood Type	wall
Venting Type	convertible
Temperature Sensor	no
Number of Fan Speeds	5
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts
Current	4 amperes

Weight and Dimensions

Depth	22 1/16 inches
Height	27 inches
Width	29 15/16 inches
Net Weight	36.2 pounds
