7
WARNING FIRE HAZARD
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages.
All exhaust must be ducted to the outside, unless using the recirculating option.
Use single wall rigid metal ductwork only.
Fasten all connections with sheet metal screws and tape all joints w/ certied Silver Tape or Duct Tape.
Some Ducting Options
Installation – Ducting Options
Roof Pitch w/
Flashing & Cap
side wall cap
w/ gravity damper
Soffit or crawl space
(blower
housing)
ductless
recirculating
side wall cap
w/ gravity damper
(blower
housing)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zephyr Essentials ZAN-E30CS and is the answer not in the manual?

Zephyr Essentials ZAN-E30CS Specifications

General IconGeneral
Colorstainless steel
Hood Typewall
Venting Typeconvertible
Temperature Sensorno
Number of Fan Speeds5
Control Typebutton
Delay Startyes
Interior Lightyes
Remote Controlno
Voltage120 volts
Current4 amperes
Weight and Dimensions IconWeight and Dimensions
Depth22 1/16 inches
Height27 inches
Width29 15/16 inches
Net Weight36.2 pounds
