PRB24C01BG Use, Care, and Installation Guide
BEVERAGE
COOLER
SINGLE ZONE
PRESRV™
Installation Instructions
Installation Clearance Requirements
When installing the beverage cooler under a counter, follow the recommended spacing dimensions
shown.
► For proper clearance of the electrical plug, allow at least 1” of clearance at the back as shown in
the diagram.
► An installation next to a wall will require a minimum 2-1/4” door clearance to accommodate the
Zephyr handle.
► The cabinet should allow at least 24” for the width and 34” for the height to accommodate the
beverage cooler.
► The power cable is located on the back right of the unit and has a length of 72” to accommodate
multiple outlet locations.
► Once you are ready to install the unit, you must adjust the feet to level the beverage cooler.
► The installation should allow the unit to be pulled forward for servicing, if necessary.
2-1/4” Min.
24” Min.
34” Min.
1” Min.
