19
PRB24C01BG Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
► To prevent damaging the door or door gasket, make sure the door is open at least 90-degrees
when pulling shelves out of the rail compartment.
► The door opens to a maximum of 135 degrees with a door stop on the bottom hinge preventing the
door from opening further.
Removing the Wooden Shelves
1. Open the door completely.
2. Remove all of the contents loaded on the shelf, if applicable.
3. Pull the shelf towards yourself until it is fully extended outward.
4. The shelf has plastic tabs on both sides indicated in the diagram below. While facing the unit,
press the plastic tab on the right side down while pulling up on the left plastic tab.
5. Evenly pull out the shelf from the track until it is completely removed from the inner compartment.
To Next Page
