Zephyr Vortex AK9028AS - Diagrams; Fan Curve & Wiring

Diagrams – Fan Curve & Wiring
0.00
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.80
0.90
1.00
1.10
1.20
1.30
1.40
1.50
1.60
1.70
1.80
1.90
2.00
0 25 50 75 100 125 150 175 200 225 250 275 300 325 350 375 400
Pressure (inAq)
Flow rate (CFM)
Fan Curve
Model: AK90 (Vortex)
AC Input: 120V, 60Hz
Outlet Diameter: 6in
3A
17
