11. Grab your drill with the 5/64 bit set to stick out about 1-1/8”, and drill three pilot holes at the
upward-facing marks, through the Cleat and into the Side.
145
Remove the clamps and set this
cleat aside.
145
12. Repeat steps 10 - 11 for the other Front Cleat.
13. The process for the two short Rear Cleats is similar, but note you use the Port piece to space them
up from the bottom and in from the back edge.
146
Be SURE to space these cleats in a little far
from the back edge! You can usually hold the rear cleats firmly in place with one hand while
drilling the pilot holes with the other; clamping should not be necessary.
147
146 147
14. While you have that 5/64 bit in place, drill four blind holes in the cabinet Bottom, about ½”
deep.
148,149
148 149
