69
2. Use a screw driver to install the handle, using the screws that came with it.
225,226
Your combo
probably shipped with a different handle than the one shown here.
225 226
The cabinet is done!
227
227
MAKING THE SPEAKER CABLE
1. Take the 6” zip wire (Part # CB11) and split the ends about ½” (13mm). Now use your flush or
diagonal cutters and cut off about 3/16” (4-5 mm) from ONE END of the RIBBED wire.
228
Cut
3/16” (4-5 mm) insulation off all four ends. Twist the exposed stranded wire ends,
229
and then
tin them with the soldering iron.
230
228 229
