INSTALLING THE BAFFLE BOARD
1. Use a hot soldering iron to melt a little hole through the grill cloth over the four mounting holes
near the corners of the baffle board.
291
=SM161
291
2. Place the cabinet on its back and drop the completed baffle into the front. Orient the baffle so
that the cable is facing toward the amp.
292,293
292 293
3. Poke a #6x1-1/4 wood screw (Part # SC61) through one of the holes and use a screw driver to
turn it a few times, just enough to mark the cleat.
294
Repeat for all four corners.
294
