86
4. Remove the baffle and use the 5/64 bit to drill four pilot holes about ½” deep into the cleats.
295
295
5. Drop the baffle back into place, careful to place it in the same orientation as previously.
6. Place a #8 Finish Washer (Part # WA10) over the end of a #6x1-1/4 wood screw (Part # SC61)
and drive it through one of the holes and into the cleat. Leave it a little loose.
296
296
7. Repeat for the other three corners, then go back and tighten all four screws.
297
297
