37
TRACTOR SURVEY
∗
∗∗
∗ DIGITAL DASHBOARD
The digital dashboard is fitted as the
standard outfit of the Z 11741 tractors.
The digital dashboard is installed if re-
quired for Z 8641, Z 9641, Z 10641,
Z 11441 tractors.
DESCRIPTION OF INSTRUMENTS
A - Signal lights
B - Air pressure gauges
C - Speedometer
D - Fuel gauge
E - Cooling liquid thermometer
F - Display
SIGNAL LIGHTS AND PUSHBUTTONS
Location of signal lights on the digital in-
strument dashboard is identical to the
analog dashboard.
21 - Pushbutton of the enginhours. Data
shown on the display.
22 - Battery voltage pushbutton. Data on
the voltage in volts will be displayed
with 0,1-V accuracy.
23 - Pushbutton of kilometers (covered
per day or since the last zeroing).
The number of kilometers will be
shown on the display. Zero setting by
pressing the button permanently.
24 - Instantaneous speed pushbutton
given in km/h on the display.
25 - P.T.O. shaft 1000-rpm pushbutton.
Rpm are displayed with a 10-rpm ac-
curacy.
26 - P.T.O shaft 540-rpm pushbutton.
Rpm are displayed with a 10-rpm ac-
curacy.
