Key Cap Labels (Master Sheet)
This page is provided as a reusable master from which you can make copies of the key cap
labels. They are correctly sized so that if you cut along the outside lines of the boxes, the
labels should just fit inside the removable covers of the programmable keys on the tone
remotes. Blanks have been provided so that you can type up your own labels if you need
to.
Installation of Key Switch Labels
Zetron provides a set of standard key switch labels with each unit. You can easily create
and print customized labels using any PC graphics or label-creation software. For best
results, create a label template that produces 13mm (0.51”) square labels. Zetron can
provide a template for you upon request.
