Section 6. Repair
6-4
MODEL 30 CONTROL BOARD (702-9321K)
Parts List (Continued)
Item Qty Reference Part Description Part
Ref.
47 1 C41 151-0130 CAP,.047uF,50V,10%,CERAMIC X7R .047
48 8 C1,C5,C12,C13, 151-0180 CAP,.1uF,50V,20%,CERAMIC Z5U .1
C31,C32,C33,C38
49 4 C19,C24,C25,C45 152-0012 CAP,.1uF,50V,5%,POLYESTER .1
50 1 C15 152-0021 CAP,.47uF,250V,10%,POLYESTER .47
250V
51 1 C8 152-0040 CAP,4.7uF,50V,20%,NON-POLAR ELECTROLYTIC,AXIAL 4.7
52 3 C21,C29,C30 152-0080 CAP,.22uF,50V,5%,POLYESTER .22
50V
53 2 C40,C39 152-0089 CAP,.001uF,50V,5%,POLYESTER .001
54 3 C7,C35,C42 154-0025 CAP,1uF,35V,10%,TANTALUM 1 TANT
55 1 C36 154-0035 CAP,2.2uF,25V,10%,TANTALUM 2.2
TANT
56 5 C6,C20,C28,C43, 154-0100 CAP,10uF,16V,10%,TANTALUM 10
TANT
C44
57 2 C2,C14 155-0083 CAP,470uF,10V,20%,RADIAL,Al-E 470
10V
58 2 E2,E1 305-0001 BEAD,3B FERRITE,W/LEADS
59 1 T1 305-2105 XFMR,TELCO MODEM, 600 OHM,80MA DC
60 1 DS4 311-0015 LED,GREEN,TRANSPARENT,T1-3/4
61 3 DS1,DS2,DS3 311-0016 LED,RED,TRANSPARENT,T1-3/4
62 1 U6 311-1001 OPTO ISOLATOR,BI-POLAR H11AA1
63 3 U1,U5,U7 316-0324 OP-AMP,BIPOLAR,358 EQUIVALENT,QUAD,DIP-14 324
64 1 U4 316-0358 OP-AMP,BIPOLAR,DUAL,DIP-8 358
65 2 VR1,VR2 316-7805 REGULATOR,+5V,1.5A,TO-220 7805
66 1 U13 321-0204 RCVR,DTMF,DIP-14 75T204
67 0 U12^ 321-6806 8 BIT CMOS OTP (68HC705A),DIP-40 ASIC
009
68 1 U8 322-0103 EEPROM,SERIAL,16K BIT,DIP-8 93C86
69 1 U9 322-9346 EEPROM,1024-BIT(64x16),SERIAL,DIP-8 64x16
70 2 U3,U2 323-4053 ANALOG SWITCH,TRIPLE SPDT,DIP-16 4053
71 2 U10,U11 324-7414 INVERTER,SCHMITT,HEX,DIP-14 74HC14
72 1 Q4 340-0014 XSTR,NPN,DARLINGTON,0.5A 30V,TO-92 MPSA14
73 2 Q7,Q8 340-3904 XSTR,NPN,40V/200MA,TO92 2N3904
74 5 Q1,Q2,Q3,Q5,Q6 340-7000 XSTR,MOSFET,N-CHANNEL,60V/ 0.2A,TO-92 2N7000
75 1 CR5 342-0001 DIODE,SILICON,1A,100V,D0-41 1N4002
76 2 CR7,CR6 342-0103 DIODE,SCHOTTKY,0.37V @ 1MA TYP SD103A
77 2 CR10,CR8 342-3009 DIODE,SILICON,100V,250MW 1N4148
78 1 CR9 343-3100 DIODE,ZENER,8.2V,1W,5% 8.2V
79 4 CR1,CR2,CR3,CR4 343-3110 DIODE,ZENER,20V,1W,5% 20V
80 1 SW1 371-0024 SWITCH,PB,SPST,MOM,R/A,PWB MNT
81 1 Y1 NOTE 1 376-0358 XTAL,3.579545MHZ,CL=18pF,HC-49
3.58MHZ
82 1 K1 380-0030 RELAY,DPDT,12 V COIL,MINI-DIP
83 1 J1 401-0080 6-PIN LO PRO R/A TELCO
84 1 P1 401-0202 10 PIN X .156 R/A CONN
85 1 J2 401-6006 6-POS MALE
86 1 JP4 403-0002 02 OF 401-0052
87 6 JP1,JP2,JP3,JP5, 403-0003 03 OF 401-0052
JP6,JP7
88 1 JP8 403-0004 04 OF 401-0052
89 1 F1 416-1202 FUSE,AGC,2 AMP,FAST-BLOW 2A
90 2 FX1,FX2 NOTE 2 416-1303 FUSE, 3/4-AMP, SLOW-BLOW,SUBMINIATURE 3/4
AMP
91 7 XJP3,7,8 (POS A) 402-3040 MINI JUMPERS
XJP1,2,6 (POS B)
XJP4 (IN)
92 2 XU8,9 407-0008 SKT, 8 PIN DIP
93 1 XU12 407-0040 SKT, 40 PIN DIP
94 1 PCB 410-9321D MODEL 30 CONTROL BOARD
95 2 XF1 416-3040 FUSE CLIP
96 4 XDS1-4 417-0010 LED MOUNT RA
NOTES: (Notes are for Production use only.)
