Section 6. Repair
6-3
MODEL 30 CONTROL BOARD (702-9321K)
Parts List
LEGEND:
+ = OPTION
# = NOT INSTALLED
^ = INSTALLED ON HIGHER ASSY
- = SUBSTITUTE PART
ZETRON MODEL 30 CONTROL BOARD PARTS LIST:
Item Qty Reference Part Description Part
Ref.
1 1 R56 101-0025 RESISTOR,10 OHM,1/4W,5%,CARBON FILM 10
2 3 R9,R12,R68 101-0047 RESISTOR,47 OHM,1/4W,5%,CARBON FILM 47
3 1 R80 101-0049 RESISTOR,100 OHM,1/4W,5%,CARBON FILM 100
4 6 R10,R19,R84,R85, 101-0057 RESISTOR,220 OHM,1/4W,5%,CARBON FILM 220
R86,R87
5 2 R72,R20 101-0059 RESISTOR,270 OHM,1/4W,5%,CARBON FILM 270
6 1 R18 101-0061 RESISTOR,330 OHM,1/4W,5%,CARBON FILM 330
7 4 R8,R49,R57,R69 101-0065 RESISTOR,470 OHM,1/4W,5%,CARBON FILM 470
8 2 R6,R11 101-0066 RESISTOR,510 OHM,1/4W,5%,CARBON FILM 510
9 3 R22,R26,R52 101-0073 RESISTOR,1.0K OHM,1/4W,5%,CARBON FILM 1.0K
10 1 R63 101-0081 RESISTOR,2.2K OHM,1/4W,5%,CARBON FILM 2.2K
11 1 R55 101-0083 RESISTOR,2.7K OHM,1/4W,5%,CARBON FILM 2.7K
12 1 R45 101-0085 RESISTOR,3.3K OHM,1/4W,5%,CARBON FILM 3.3K
13 1 R14 101-0089 RESISTOR,4.7K OHM,1/4W,5%,CARBON FILM 4.7K
14 2 R27,R29 101-0090 RESISTOR,5.1K OHM,1/4W,5%,CARBON FILM 5.1K
15 2 R74,R54 101-0091 RESISTOR,5.6K OHM,1/4W,5%,CARBON FILM 5.6K
16 2 R71,R17 101-0093 RESISTOR,6.8K OHM,1/4W,5%,CARBON FILM 6.8K
17 1 R36 101-0096 RESISTOR,9.1K OHM,1/4W,5%,CARBON FILM 9.1K
18 10 R28,R41,R51,R61, 101-0097 RESISTOR,10K OHM,1/4W,5%,CARBON FILM 10K
R64,R65,R66,R81,
R82,R83
19 2 R59,R43 101-0099 RESISTOR,12K OHM,1/4W,5%,CARBON FILM 12K
20 1 R24 101-0101 RESISTOR,15K OHM,1/4W,5%,CARBON FILM 15K
21 1 R76 101-0104 RESISTOR,20K OHM,1/4W,5%,CARBON FILM 20K
22 4 R7,R44,R70,R73 101-0105 RESISTOR,22K OHM,1/4W,5%,CARBON FILM 22K
23 1 R21 101-0109 RESISTOR,33K OHM,1/4W,5%,CARBON FILM 33K
24 5 R25,R30,R50,R60, 101-0113 RESISTOR,47K OHM,1/4W,5%,CARBON FILM 47K
R75
25 1 R15 101-0115 RESISTOR,56K OHM,1/4W,5%,CARBON FILM 56K
26 3 R16,R34,R88 101-0117 RESISTOR,68K OHM,1/4W,5%,CARBON FILM 68K
27 16 R23,R31,R32,R33, 101-0121 RESISTOR,100K OHM,1/4W,5%,CARBON FILM 100K
R35,R37,R38,R39,
R40,R53,R67,R78,
R79,R92,R93,
RX1 NOTE 3
28 1 R48 101-0123 RESISTOR,120K OHM,1/4W,5%,CARBON FILM 120K
29 2 R47,R46 101-0129 RESISTOR,220K OHM,1/4W,5%,CARBON FILM 220K
30 2 R13,R58 101-0131 RESISTOR,270K OHM,1/4W,5%,CARBON FILM 270K
31 4 R62,R77,R89,R91 101-0145 RESISTOR,1.0M OHM,1/4W,5%,CARBON FILM 1.0M
32 2 RV2,RV1 105-0001 VARISTOR,250VAC,70J 250VAC
33 0 R1#,R2# 106-1175 RESISTOR,FUSIBLE,75 OHM,1W,5% 75-1F
34 2 R5,R3 107-0003 POT,2K OHM,1 TURN,R/A 2K
35 1 R4 107-0015 POT,50K OHM,1 TURN,R/A 50K
36 1 R42 107-0202 POT,2K OHM,1 TURN 2K
37 1 R90 107-0502 POT,50KOHM,1 TURN 50K
38 1 RP3 119-0021 R-NETWORK,R/2R,100K/200K,SIP-10
100K/200K
39 1 RP2 119-0025 R-NETWORK,10K OHM x 4,ISOLATED,SIP-08 10K
40 1 RP1 119-0026 R-NETWORK,2K OHM x 4,ISOLATED,SIP-08 2K
41 3 C9,C10,C11 150-0096 CAP,1000pF,1KV,10%,CERAMIC DISC,Y5P .001
1KV
42 4 C16,C23,C26,C37 151-0020 CAP,.001uF,100V,10%,CERAMIC X7R .001
43 1 C22 151-0027 CAP,270pF,100V,10%,CER. NPO(USE 151-0028) 270pF
44 1 C17 151-0047 CAP,470pF,100V,10%,CERAMIC NPO 470pF
45 2 C34,C27 151-0100 CAP,.033uF,50V,10%,CERAMIC X7R .033
46 3 C3,C4,C18 151-0120 CAP,.01uF,50V,10%,CERAMIC X7R .01
