3TECHNICAL DATA
3.1 TECHNICAL DATA
OIL PUMP FLOW RATE:
19 litres at 4500 rpm
OPERATING PRESSURE AT 4500 RPM:
14 - 16 bar
OPERATING PRESSURE AT 1500 RPM:
12 - 15 bar
OPERATING PRESSURE AT 700 RPM:
8 - 12 bar
LUBRICATION PRESSURE AT 1500 RPM:
> 0.5 bar
MAX. TRANSVERSE INCLINATION DURING OPERATION:
+/- 15 deg
MAX. LONGITUDINAL INCLINATION DURING OPERATION:
+/- 25 deg
3.2 OIL TYPE
OIL RECOMMENDED IS SAE 30
TYPE MASS (WITHOUT OIL) OIL TEMPERATURE [°C] OIL CAPACITY [DM3]
Main Unit 21 40 to 80 1.1 to 1.3
40 V Drive / 41 V Drive 16 40 to 80 0.9 to 1.0
TYPE SPECIFICATION VISCOSITY
SAE 30 SAE 30 102 cst (40°C) - 11.6 cst (100°C)
Mobil ATF 200 ISO 46 45 cst (40°C) - 8 cst (100°C)
Mobil ATF 220 DEXRON II D ISO 32 35.2 cst (40°C) - 6.9 cst (100°C)
