ZF 80-1 A new version User Manual

SHIM
To determinate the correct preload of the tapered roller
bearings.
- P/N 20.1005.00 ZF 63 A
- P/N 20.1018.00 ZF 63
- P/N 20.1016.00 - ZF80 A - ZF 80-1 A - ZF 85 A
SPECIAL HEX HEAD BOLT WITH BEARING
for measuring the bearing clearance intermediate shaft
P/N. 224.836.008 (458105)
PUNCH
for assembly Seal - suction pipe
- P/N 20.1021.00 ZF 80 A - ZF 80-1 A - ZF 85 A
- P/N 20.1029.00 ZF 63 A - ZF 63
CENTRE SQUARE PUNCH To position the oil suction
pipe into housing P/N 20.1041.00
8
Repair Manual and Spare Parts List Section 2
