Shenzhen Zhurui Technology Co.,Ltd.
11 / 13
Output protection settings
Screen setting
System settings (Clear accumulated electricity consumption, clear history recording , restore the factory settings)
1. See the “Process of entering into setting pages”, enter the Output Protect
setting page.
2. According to the alarm settings, complete the output protection parameter
settings of voltage, current, power and temperature.
3. If needed, press “
” key to check or uncheck the “Launch overload”
checkbox, press “
” key to jump to next setting item. If the start-up
current of the equipment test (e.g. the motor) exceed the output protection
current, then the “Launch overload” checkbox need to be checked, if this
checkbox is checked, the machine will not monitor the output current and
power exceed the max current and power limit which was set before, “Launch
overload” will not take effect when the load current less than 2A.
4. If needed, press “
” key to check or uncheck the “Auto Recovery”
checkbox, press “
” key to move the cursor to the “OK” button; if this
checkbox is checked, when the machine is in output protection and power off
the outlets, one minute later if the voltage, current, power or temperature of
the machine are not in the output protection limits, the machine will
automatically power on the outlets to the test equipment.
5. Press “
” key to save the settings and quit. Press “ ” key to quit
1. See the “Process of entering into setting pages”, enter the screen setting page.
2. Press “
” key or “ ” key to adjust the time option for turn off the
screen, press “
” key to select the option, now the cursor jump to the
“OK” button.
3. Press “
” key to save the settings and quit. Press “ ” key to quit
without any changes.
1. See the “Process of entering into setting pages”, enter the system setting page.
2. Press “
” key or “ ” key to move the cursor to the item need
operation, then press “ ” key, the confirm dialog will pop up at this time.
3. Press “
” key or “ ” key to decide whether to perform the operation
or not, press “
” key to perform, press “ ” key to quit and not perform
this operation.
4. Pease use this function cautiously, especially “Factory Reset
” will clear all the
records.
