Zibro S1126 - Parts Identification

4
5
B PARTS
The diagrams in these instructions are based on a standard model.
The air conditioner you have pur
chased may be a different model.
Air inlet
Front panel
Emergency button
Display
Air outlet
Vertically
adjustable vane
Horizontally
adjustable vane
Active carbon
filter (optional)
Healthy air filter
(optional)
Air filter
Remote control
Air inlet
Drainage hose
Pipes (not included)
and power cable
Air outlet
INDOOR UNIT
OUTDOOR UNIT
Note: Condensation is drained
during COOLING or DR
YING
