11 Diagnostic with hand held terminal A-G-247NW
11.1 Diagnostic menu for ECblue Basic
The diagnostics menu supplies information about the momentary operating condition of the device.
Diagnostic
32.0 °C
IGBT Temp.
Display of the internal temperature of the power semiconductor.
32.0 °C
Inside Temp.
Display of electronics internal temperature.
32.0 °C
MCU Temp.
Display of the internal temperature of the microcontroller.
0 %
E1 Input
Signal height at analog input1“E1”.
565 V
DC-Voltage
For 1 ~ types: DC-link voltage constantly approx. 400 V.
For 3 ~ types DC-link voltage without load = peak value oft the input voltage.
In a three-phase supply network with 400 V, an intermediate circuit voltage of ca. 565 V
results. This voltage sinks slightly under load.
330 V
Line voltage
Line voltage
0
Stateflags
Stateflags
0
Faultflags
Faultflags
2
PIN-Accesslevel
Momentarily adjusted PIN-Accesslevel (
Controller Setup).
11.2 Diagnostic menu for Fcontrol / Icontrol Basic / PMIcontrol Basic M
The diagnostics menu supplies information about the momentary operating condition of the device.
Diagnostic
32.0 °C
IGBT Temp.
Display of the internal temperature of the power semiconductor.
32.0 °C
Capacitor
Display of electronics internal temperature.
32.0 °C
MCU Temp.
Display of the internal temperature of the microcontroller.
32.0 °C
Output filter
Only in version with integrated sine filter.
0 %
E1 Input
Signal height at analog input1“E1”.
565 V
DC-Voltage
The intermediate circuit voltage without load is the peak value of the input voltage.
In a three-phase supply network with 400 V, an intermediate circuit voltage of ca. 565 V
results. This voltage sinks slightly under load.
330 V
Line voltage
Line voltage peak value.
0
Stateflags
Not active in devices with integrated display.
0
Faultflags
Not active in devices with integrated display.
2
PIN-Accesslevel
Momentarily adjusted PIN-Accesslevel (
Controller Setup).
