9 Enclosure
9.1 Technical data
Type MPG-200V MPG-1000V MPG-6000V
Part-No. 384057 384058 384059
Voltage supply 10...24 V DC (+20 %)
Protected against reverse polarity
Output signal 0...10 V (characteristic linear)
@ U
S
10 V DC @ U
S
13...24 V DC
Max. load output 0...10 V
(short-circuit-proof)
0.3 mA 10 mA
Max. current consumption ca. 6 mA 14 mA
Pressure connections “+, -” Hose connectors d = 5 / 6 mm (0.20 / 0.24 inch)
Housing PC (polycarbonate)
Fire protection classification UL94V0
Use position vertical (measuring depends on position)
Protection rating IP54 according EN 60529
Weight approx. 210 g (0.46 lb)
Permissible temperature range for operation -10...70 °C (14...158 °F)
Permissible temperature range for storage and
transport
-30...70 °C (-22...158 °F)
Permissible rel. humidity 85 % no condensation
One-sided permissible overload 0.1 bar (80 in.wg)
Burst prssure at room temperature: 0.2 bar (80 in.wg)
at 70 °C (158 °F): 0.15 bar (60 in.wg)
Maximum cross section of terminals 1.5 mm
2
/ AWG16
Interference emission according EN 61000-6-3 (domestic household applica-
tions)
Interference immunity according EN 61000-6-2 (industrial applications)
Operating Instructions MPG-..V Enclosure
L-BAL-E248-GB 1931 Index 003 Part.-No. 00163446
9/12
