23:00
ON
Turn-on time
05:00
OFF
Turn-off time
Information
Automatic daylight saving time only applies to countries in the
Northern hemisphere.
The time is put forward from 2:00 am to 3:00 am on the last
Sunday in March and put back from 3:00 am to 2:00 am on the last
Sunday in October.
If other dates for the switch over between daylight saving time and
winter time are required, the clock must be changed by hand
(manually) on the respective date.
8.7 MODBUS SLAVE
8.7.1 Address and interface parameters
Addressing and configuration of the MODBUS Slave interface.
Via this interface the device can be networked with a master
building control system, the device then operates as a pure Slave
and uses the MODBUS-RTU protocol.
The connection is made to the terminals “A (D+)”, “B (D-)” of the
MODBUS Slave interface (see installation / RS-485 interfaces for
MODBUS RTU).
Operating Instructions UNIcon CPG-..AVC Programming
L-BAL-E286-GB 1904 Index 004 Part.-No.
42/52
