Default settings and firmware version
When changing programs, all parameters are reset to the *default settings.
Menu
item
Parameter / Unit
Default setting
Users
data
CEI 0-21
DEWA
3AC+N
230V
3AC
400V
1AC+N
230V
3AC+N
230V
3AC
400V
3AC
100V
Pr1
Pr2
Pr3 *
Pr4
Pr5
Pr6
U,,
59.S2
59>S2
u,,
Alarm on/off
Off
Off
Off
Off
Off
OFF
u,,
Overvoltage
V
264
458
264
264
458
115
H,,
Hysteresis
V
10.5
17.5
10.5
10.5
17.5
4.5
dal
Response time
s
0.10
0.10
0.10
0.10
0.10
0.10
dof
OFF-delay
s
0
0
0
0
0
0
U,
59.S1
59>S1
u,
Alarm on/off
On
On
On
On
On
On
u,
Overvoltage
V
264
458
264
253
438
120
H,
Hysteresis
V
10.5
17.5
10.5
10.5
17.5
4.3
dal
Response time
s
0.20
0.20
0.20
0.20
0.20
0.60
dof
OFF-delay
s
0
0
0
0
0
0
UM
59-Av
UM
Alarm on/off
On
On
On
On
On
Off
UM
Overvoltage
V
253
438
253
253
438
110
HM
Hysteresis
V
10.0
17.5
10.0
10.0
17.5
4.3
dal
Response time
s
3.00
3.00
3.00
3.00
3.00
3.00
dof
OFF-delay
s
0
0
0
0
0
0
U_
27.S1
27<S1
u_
Alarm on/off
On
On
On
On
On
On
u_
Undervoltage
V
196
339
196
196
339
85
H_
Hysteresis
V
8.0
13.5
8.0
8.0
13.5
3.5
dal
Response time
s
1.50
1.50
1.50
0.40
0.40
1.50
dof
OFF-delay
s
0
0
0
0
0
0
U__
27.S2
27<S2
u__
Alarm on/off
On
On
On
On
On
On
u__
Undervoltage
V
34.5
60
34.5
92
159
3.0
H__
Hysteresis
V
3.7
3.7
3.7
3.7
6.4
1.5
dal
Response time
s
0.20
0.20
0.20
0.20
0.20
0.20
dof
OFF-delay
s
0
0
0
0
0
0
F,,
81.S2
81>S2
F,,
Alarm on/off
On
On
On
On
On
On
F,,
Overfrequency
Hz
51.50
51.50
51.50
54.00
54.00
54.00
H,,
Hysteresis
Hz
0.10
0.10
0.10
0.10
0.10
0.10
dal
Response time
s
0.10
0.10
0.10
10.0
10.0
10.0
dof
OFF-delay
s
0
0
0
0
0
0
F,
81.S1
81>S1
F,
Alarm on/off
Off
Off
Off
Off
Off
Off
F,
Overfrequency
Hz
50.20
50.20
50.20
52.50
52.50
52.50
H,
Hysteresis
Hz
0.10
0.10
0.10
0.10
0.10
0.10
dal
Response time
s
0.10
0.10
0.10
0.10
0.10
0.10
dof
OFF-delay
s
0
0
0
0
0
0
