Assembly
Figure 1. &DUHIXOO\UHPRYH\RXU=LS¶UGlider knee scooter from its
packaging. Insert the mainframe into the rear frame of the knee
scooter. Ensure that the lower mainframe clicks into place. Tighten
the knob on the upper mainframe securely.
Figure 2. Install the brake cable clip to the lower
mainframe.
Figure 3. Insert the knee pad into the knee pad post. Adjust the height
of the knee pad post by raising or lowering the knee pad post. Secure
the height inserting the seat post pin with knob. Tighten the seat post
pin with knob securely.
Figure 4. From its folded position raise the steering column. Lock the
steering column into place by tightening the lever located at the base of
the column. Fold the steering column pushing downwards.
