7
FITTING THE HOSE CLAMPS
The hose clamps are attached around the front fork and tightened using a 7 mm socket or a slotted
screwdriver (a). It is important to ensure that both hose clamps are tted at the same height. Do not
tighten these fully until later. Any rubber that protrudes beyond the hose clamp can be cut off.
When tting to the rear wheel you do the same procedure, but attach the clamps
to the seat stays instead.
6
a.
7
