Zipro Lite - PARTS LIST; Component Details

23
EN
PARTS LIST
No. Description Quantity No. Description Quantity
01 Main frame 1 29 Rear roller 1
02 Bracing tube 1 30 Cylinder 2
03 Right handrail column 1 31 Needle roller bearing 2
04 Left handrail column 1 32 Washer
∮
9*
∮
16*t1.5 6
05 Left column connecting rod 1 33 Screw M5*10 4
06 Right column connecting rod 1 34 Screw M8*12 2
07 Cylinder fixture 2 35 Screw M8*16 4
08 Handrail 1 36 Washer D8 6
09 Motor socket 1 37 Screw M8*25 1
10 Running board t12*460*1010 1 38 Screw M8*35 2
11 Running belt t1.4*380*2260 1 39 Screw ST4.2*12 9
12 Belt drive 160-J5 1 40 Screw ST4.2*16 6
13 Motor cover 1 41 Screw ST4.2*16 7
14 Lower motor cover 1 42 Screw M6*30 6
15 Left rear cover 1 43 Screw M6*40 2
16 Right rear cover 1 44 Bolt M6*50 3
17 Lateral rail 2 45 Nut M8 S13 4
18 Shock-absorbing pad 8 46 Screw M8*25 2
19 Handling wheel 2 47 Screw M6*16 8
20 Supply cable clamp 1 48 Nut M10 S17 2
21 Shock-absorbing foot 2 49 Screw ST2.9*6 8
22 Handlebar 1 50 Shaft fastener D8 2
23 Shock-absorbing pad
∮
8*
∮
18*19 2 51 Console 1
24 Shock-absorbing lock 24*35*11 2 52 Control panel 1
25 Column plug 2 53 DC motor 1
26 EVA foam 20*2*400 1 54 Curved washer 2
27 Foot 2 55 Switch 1
28 Front roller
∮
36*429*
∮
100*
∮
1 56 Screw M6*20 S5 2
57 Double-sided adhesive tape
20*2*950
4 61 Wrench 80*80*5 S5 1
58 Single cable 2 62 Fixed filter panel 1
59 Power supply line 1 63 Generator 1
60 Remote control 1 64 Filter 1
