SG6 CAN Bus Interface
2
D01596-03
Mechanical dimension
90.0
220.0
250.0
276.0
N.B. All dimensions are expressed in mm
Drilling details
233.5
203.5 = =
=
=
N.B. All dimensions are expressed in mm
