Zivan SG6 CAN Bus Interface - Technical Features; Mains Side Specifications; Battery Side Specifications; General Specifications

English SG6 CAN Bus Interface
12 D01596-03
TECHNICAL FEATURES
Ta=25°C unless otherwise specified
Mains side
Description Symbol Test Condition Value and/or Range Unit
Supply Voltage Vin - 230 ± 10% Veff
Frequency f - 50 ÷ 60 Hz
Absorbed Maximum Current per phase. * If
max
P = P
max
15 Aeff
Inrush Current - Vin=230Veff < 3 A
Power Factor
cosϕ
P = P
max
0,66 -
Absorbed Minimum Power Pin
min
End of charge < 5 W
Absorbed Maximum Power Pin
max
P = P
max
2,2 kW
* Maximum value per model. For the effective current absorption please refer to the charger’s identification label.
Battery side
Description Symbol Test Condition Value and/or Range Unit
Output current I - See curve ± 5% -
Maximum output current I1 Phase 1 See curve ± 5% A
Output current ripple - I = I1 < 5% -
Absorbed current I
a
Equipment turned off < 0,5 mA
Output voltage U - See curve ± 0,5% -
Constant output voltage U1 On the OUT clamps with I = 90% of I1 See curve ± 0,5% V
Thermal compensation of output voltage dU1/dT Phase 2 -5 mV/(°C·cell)
Operating range of Temperature Sensor
∆T
- from -20 to +50 °C
Output voltage ripple - U = U1 < 1% -
Maximum power supplied P
max
U = U1, I = I1 2000 W
Output capacity C - Depend on the model
(>0,2)
mF
General
Description Symbol Test Condition Value and/or Range Unit
Operating range of temperature
∆T
- from -20 to +50 °C
Maximum relative humidity RH - 90% -
Switching frequency f
c
- 70 ± 10% kHz
Efficiency
η
At each operation condition ≥90% -
Maximum size a×b×c Without connecting cable 276×220×94,2 mm
Weight - Without connecting cable 5,5 kg
Enclosure class - - IP44 -
Protection and Safety
Description Symbol Test Condition Value and/or Range Unit
Insulation - Mains to Battery side 1250 V
AC
Insulation - Mains side to Earth 1250 V
AC
Insulation - Battery side to Earth 1250 V
AC
Leakage current (EMC Filter) I
L
Supplied equipment < 7 mA
Input fuses F1 Inside the equipment 20 A
Output fuse F5 To be externally mounted
about 1,2×I1
A
Minimum output voltage of operation (Battery
Detector)
- Equipment turn on See curve V/cell
Maximum output voltage Um Phase 3 (IUIa - IUIUo) See curve V
Reverse output polarity - At the connection to the Battery Protection provided by
external fuse
-
Thermal protection of semiconductors
(Temperature of Thermal Alarm)
- 100 °C
Safety Requirements (Rules) - EN60335-1, EN60335-2-29 - -
EMC Requirements (Rules) - EN55011 (conducted EMC) - -
This device is in conformity with the Low Voltage directive 2006/95/CE.
